Ventilair Engineers Pvt. Ltd. (VEPL) is a leading manufacturer of technically advanced Hybrid Hospital Effluent Treatment Plants (ETP) engineered specifically for healthcare facilities to treat biomedical wastewater in compliance with regulatory standards.
Our systems are designed to handle complex hospital effluent containing high organic load, pathogens, pharmaceutical residues, disinfectants, laboratory chemicals, and suspended solids.
🔹 Capacity Range
VEPL Hospital Hybrid ETP systems are available in capacities starting from:
1 KLD to 1000+ KLD
(Customized design available as per project requirement and influent load characteristics.)
🔹 Application Areas
✔ Multi-Specialty Hospitals
✔ Government & Private Hospitals
✔ Medical Colleges
✔ Diagnostic & Pathology Laboratories
✔ Super Specialty Healthcare Units
✔ Research & Biomedical Facilities
🔹 Technology Configuration – Hybrid System
VEPL Hybrid ETP integrates Physico-Chemical + Biological + Tertiary Treatment to ensure maximum contaminant removal efficiency.
Treatment Process Sequence:
Bar Screen Chamber
Collection & Equalization Tank
pH Correction System
Flash Mixer & Flocculator
Tube Settler / Primary Clarifier
MBBR (Moving Bed Biofilm Reactor)
Secondary Clarifier
Pressure Sand Filter (PSF)
Activated Carbon Filter (ACF)
Ultra Filtration (UF) – Optional (for stringent discharge norms)
Final Disinfection (Chlorination / UV System)
🔹 Technical Specifications
• Technology: Hybrid (Physico-Chemical + MBBR Based Biological Treatment)
• Capacity: 1 KLD to 1000+ KLD
• Construction: MS Fabricated Tanks with FRP Internal Coating / RCC Civil Option
• Surface Protection: Anti-Corrosive FRP Lining
• Aeration System: Fine Bubble Diffused Aeration
• Blowers: Twin Lobe / Roots Type
• Bio Media: High Surface Area MBBR Media
• Sludge Handling: Filter Press / Sludge Drying Bed
• Automation: Semi / Fully Automatic (PLC Based Optional)
• Standby Equipment: Pumps & Blowers Provided
• Compliance: Designed as per CPCB & State PCB Norms
🔹 Expected Treated Water Parameters
(Subject to Influent Quality & Treatment Configuration)
• pH: 6.5 – 8.5
• BOD: < 10–30 mg/L
• COD: < 50–250 mg/L
• TSS: < 10–30 mg/L
• Oil & Grease: < 10 mg/L
Final treated water standards are designed as per respective State Pollution Control Board discharge requirements.
🔹 Key Features
✔ Designed for High Pathogen & Pharmaceutical Load
✔ Efficient Removal of BOD, COD & TSS
✔ Compact & Odor-Controlled Design
✔ Energy Efficient Operation
✔ Low Maintenance Requirement
✔ Zero Liquid Discharge (ZLD) Option Available
✔ Packaged / Underground / Containerized Installation
🔹 Major Locations Served (PAN India)
Delhi | Noida | Gurugram | Faridabad | Jaipur | Chandigarh
Mumbai | Pune | Ahmedabad | Surat | Vadodara
Bangalore | Chennai | Hyderabad | Coimbatore
Kolkata | Indore | Bhopal | Raipur | Nagpur | Guwahati
Ventilair Engineers Pvt. Ltd. (VEPL) delivers technically robust, regulatory-compliant, and performance-oriented Hybrid Hospital ETP systems from 1 KLD to 1000+ KLD capacity, ensuring safe discharge and environmental protection.
For technical consultation, layout drawings, GA drawings, or project proposals, connect with VEPL.
