Environment is the mixture of our life source, as we know that we are made from five elements i.e., Ether (Akash), Wind (Vayu), Fire (Agni), Earth (Prithvi), Water (Jal). All elements contain the equal importance in our life.
Water is Precious so we work with this Aim- (SAVE, TREAT & REUSE WATER)
Now-a-days the “GOVERNMENT & NGT” is very strict towards the usage and drainage of water due to the scarcity. After the strictness of government, all industries are facing a big problem (Who use water in their commercial work). To discharge the water “CPCB” want to drain the water at given fixed norms but, a small company cannot spend lot of money on this. Keeping in mind the problem of small industries, we have worked out a solution for them, especially for AUTOMOBILE (car washing) and PLASTIC DANA INDUSTRY, who use the small amount of water and are obliged to reuse water again.
We want to describe our both the new products, which are small and specially designed & manufactured for the small industry or for the small amount of water.
We have launched a product “NANO ETP”, which is effective and impressive for all kind of small It is a complete ETP, based on manual Physico-chemical method with continuous flow. Water flow rate will be 400 ltr/h. We are giving you a complete ETP in low cost, effective for treating the water, which would be reused in industrial process and horticulture. It is a packaged & skid mounted type ETP in an Exciting Fix starting price 175000/-.
“Waste water filtration unit” is a simple effluent filtration unit start under one lakh Fix price, which is SKID MOUNTED, able to remove mud, oil & grease, within a limit of BOD & TSS which is given in the quotation sheet. It can be used in Automobile and Plastic Dana manufacturing industries, process is just Save, Treat & Reuse Water.
“NANO” ETP
Screen Chamber With screen
600 x 600 x 600 mm Depth
Brick Work Client’s Scope
Mud Trap 1000 x 1000 x 1800 mm Depth
Oil & Grease Trap
1000 x 1000 x 1000 mm Depth
Collection Tank 1000 x 2000 x 1800 mm Depth
Equalization Tank 1000 x 2000 x 1800 mm Depth
CIVIL WORK FOR SKID MOUNTED NANO ETP (400 LTRS. /HOUR) PLATFORM FOR SKID OVER THE TANK -2000 MM X3000 MM X 2000 MM HT.
ETP SKID – 12OO MM X 2000 MM LENGTH
SKID MOUNTED NANO ETP
Design, Supplying, Installing, Testing & Commissioning of Effluent Treatment Plant capacity 400 LTRS. PER HOUR
Nature of effluent – Industrial waste, washing waste water etc.
Daily average flow Sewage + Tradeeffluent
pH- 6-8.5
TSS- 300-400Mg/L
BOD- 250-300 Mg/L
COD-400 -600 Mg/L
Oil& Grease-50Mg/L
Sewage discharge standards after Treatment
pH- 6.5-8.5
BOD5-Lessthan30 Mg/L
TSS- Lessthan50Mg/L
COD- Lessthan150Mg/L
Oil& Grease-Lessthan10Mg/L
Sewage discharge standards after treatment(After
Ultra Filtration Treatment)
pH- 6.5-9.0
BOD5-Lessthan10Mg/L
TSS- Lessthan30Mg/L
COD- Lessthan50Mg/L
Oil & Grease-<5MG/L
Skid Mounted Nano Effluent Treatment Plant shall include the following items:
Daily average flow Trade effluent
Mud Chamber Screen with Frame,
Settling / Clarifier Tank with Ladder
Clear Water Tank
Filtration through MGF & ACF
Effluent transfer pump
Filter feed pump
Air Compressor
Sledge Drying Bed
Piping, valves etc
Dosing Tanks
Rota Meter
Electrical MCB Box
SCOPE OF WORK:
Design and submission of drawings
Supply of all the mechanical equipment
Supply of required electrical MCB
Erection of all the mechanical equipment of ETP
BENEFITS OF NANO ETP: -
SEMI – AUTOMATIC UNIT
COPE OF WORK:
Design and submission of drawings
Supply of all the mechanical equipment
Supply of required electrical MCB
Erection of all the mechanical equipment of ETP
BENEFITS OF NANO ETP: -
SEMI – AUTOMATIC UNIT
LOW-COST PRODUCT ONLY Rs. 175000 INR LESS FOOT PRINT (SPACE SAVING) CONTINIOUS FLOW UNIT
RECYCLING UNIT
MAXIMUM PLANT IN M.S WITH FRP LONG LASTING DURABIULTY
READY TO INSTALL
FLOW RATE – 400 LTRS. PER HOUR
EFFECTIVE TO TREATING INDUSTRIAL WASTE WATER PACKAGED & SKID MOUNTED TYPE
EASY TO OPERATE EASY TO MOVE
HUSTLE FREE INSTALLATION LITTLE MAINTENANCE EXCELLENT RESULT
PRICELIST WITH MODEL OF NANO PLANT (400L/HOUR)
NANO ETP & BIOLOGICAL
VE/M/NETP/1 179999
VE/S/NETP/2 (WITHOUT SKID) 229888
VE/M/NSETP/3 (WITHOUT DOSING PUMP) 229888
VE/S/NSETP/4 259999
